Why 4G Body Camera?
A 4G body camera offers real-time connectivity, enabling law enforcement and security personnel to stream live video, upload footage instantly, and stay connected with command centers. With built-in 4G LTE support, a 4G body camera enhances situational awareness, allowing teams to respond quickly and make informed decisions on the ground. This advanced communication capability ensures faster incident reporting and more efficient coordination during critical operations. Whether in urban patrols or remote fieldwork, a 4G body camera delivers the speed, reliability, and mobility professionals need in today’s fast-paced security environments.
4G Body Camera Specifications
|
General | |
|
Internal Memory |
2+16GB standard configuration |
|
External Memory |
External card up to 512GB micro SD card |
|
Display |
2.8-inch IPS screen 480 (RGB)*640, narrow frame + ON CELL multi-touch scree |
|
Lens |
Main camera: OV4689 4MP; F/NO=2.4; |
|
View Angle |
130° Wide Angle |
|
Speaker |
12*25mm 1.5W BOX high power waterproof speaker |
|
Sensor |
Acceleration sensor (standard), support gyroscope (optional) |
|
USB Connector |
TYPE C interface, which can be connected to an external camera, video output line, earphone line, etc. |
|
Dimensions(H×W×D) mm |
92*72*24 mm |
|
Weight (g) |
188 |
|
Wireless transmission | |
|
4G Network |
YES |
|
GPS Positioning |
Built-in GLONASS/GPS combined positioning + AGPS, support Beidou / Galileo |
|
WiFi |
Support 802.11b/g/ac dual-band wifi, 2.4GHz+5GHz |
|
Bluetooth//NFC |
Built-in Bluetooth 5.0, standard NFC |
|
LTE |
2G：GSM(B2/3/5/8)、 FDD（B1/2/3/4/5/7/8/20/28） |
|
CDMA |
TD-SCDMA 38/39/40/41 |
|
WCDMA |
WCDMA（B1/5/8） |
|
GSM |
GSM (B2/3/5/8) |
|
Video and Photo | |
|
Video Encoding & Format |
H.264/H.265 high-definition encoding |
|
“Photo Resolution & |
5M/12M/20M/25M/30M/40M/48M/54M |
|
Video Resolution |
2560×1440 30P; 2304x129630P; 1920×1080 30P； 848×480 30P. |
|
Pre-recording |
5s/10s/20s/30s |
|
Post-recording |
5s/10s/20s/30s/60s/300s/600/1800s |
|
Platform | |
|
Push To Talk over Cellular |
YES |
|
Voice and video intercom |
YES |
|
Face/License Plate Recognition |
Optional(Support customization) |
|
Commander Platform (RTMP, RTSP monitor, live streaming) |
YES |
|
Camera | |
|
Number of cameras |
2 |
|
Main camera: |
Main camera: OV4689 4MP; F/NO=2.4; |
|
Front Camera |
Front secondary camera: SC530AI 5M; AF acmera |
|
Rear Camera |
– |
|
Pixel |
4MP; 5MP |
|
Aperture |
F2.4 |
|
Battery | |
|
Capacity (mAh) |
3050mAh |
|
The backup battery can be replaced |
YES |
|
Shooting time after full charge |
10H(1080P/30FPS) |
|
Recharging method |
Adapter/PC-USB auxiliary charging/car USB, with fast charging function, 5V/2A charging |
|
Reliability | |
|
Drop Test |
30 times on any 6 surfaces within 2 meters without damage |
|
Dust/ Water Protection |
IP68 |
|
Operating Environment |
Temperature: -30～55 ℃, relative humidity: 40% ～Relative 80% |
|
Others | |
|
Night Vision |
Infrared light can cover 70% of the effective area within the viewing angle range at a distance of 5 meters, and the viewing distance is 15 meters |
|
Snapshot |
YES |
|
SOS Button |
YES |
|
Voice Prompt |
YES |
|
Voice Control |
YES |
|
Audio and video recording in car/loop mode |
YES |
|
Rotatable Shoulder clip |
YES |
|
What’s In The Box |
USB Cable, Shoulder Clip, Charging Station, Spare Battery, Charger Adapter (5V 2A) |
|
